EV Battery-Tray Reinforcement — Roll-Formed 980MPa-Class Steel
980MPa-class steel that cracks in stamping, mass-produced via roll forming + laser welding for a major EV maker's battery trays.
- 01
Challenge
Reinforcement beams inside an EV battery tray must deliver crash-grade strength and range-saving light weight at once. In conventional stamping, 980MPa-class steel suffers hard-to-control springback and cracking, making yield unstable.
- 02
Approach
Roll forming bends the steel gradually, keeping 980MPa-class material stable. Partner factory BRFM pairs in-house-designed roll tooling with an in-line laser-welding line to produce closed-section beams continuously, with 100% in-line dimensional monitoring.
- 03
Outcome
Now in mass production for a major EV maker's battery trays — holding material cost below aluminum extrusion while meeting crash targets. The same section know-how extends to energy-storage (ESS) enclosure frames.
Key specs
- Material
- HSS HC550/980DP
- Process
- Roll forming + in-line laser welding
- Factory certifications
- IATF 16949 / ISO 9001 / ISO 14001
- Production stage
- Mass production (OEM supply)
Partner factory
BRFM Roll Forming (Suzhou)
Changshu, Suzhou, Jiangsu · IATF 16949 / ISO 9001 / ISO 14001 / ISO 45001
The cases on this page are the partner factories' own production records (based on each company's materials, with the factory named on every case). For similar sourcing or manufacturing needs, FENTEX acts as your single point of contact.
Considering a project like this one?
We'll check feasibility and rough cost for similar parts, free of charge. A drawing or photos make it faster.
